This page lists elements that turn riders upside-down. For a list of all other elements, see Elements.

Inversions are elements of a roller coaster that turn the train upside-down. They are most commonly found on steel roller coasters, however, Outlaw Run and Hades 360, wooden coasters, feature inversions.

Types of Inversions Edit

Barrel Roll Edit

BarrelRollElement

A Barrel Roll.

A Barrel Roll (also known as a "Heartline Roll") is an element in which the track twists 360° around the train, leaving the train twisting in a straight line around the line of riders' center of balence (at about heart level, hence the name).


Batwing Edit

A Batwing is a double inversion which flips over a 90° half-corkscrew and a half-loop followed by the same maneuver in reverse. Arrow Dynamics calls this element a boomerang.


Cobra Roll Edit

Raptor cobra roll

A Cobra Roll.

A Cobra Roll is a double inversion consisting of a half-loop, followed by two mirrored half-corkscrews, and finishing with another half-loop. Arrow Dynamics calls this element a batwing.


Corkscrew Edit

CorkscrewElement

A Corkscrew.

A Corkscrew is an inversion that resembles a vertical loop that has been stretched so that the entrance and exit points are a distance away from each other. It is basically a combination of a loop and a barrel roll. The riders are inverted at a point angled 90° horizontally from the incoming track. Often Corkscrews are found in pairs. You also occasionally see triple corkscrews.

If you were looking for a Roller Coaster and were redirected here, go to Corkscrew (Disambiguation)



Cutback Edit

DrachenFireCutback

A Cutback.

A Cutback is an inversion similar to a Corkscrew, except, the second half is mirrored, so that the train exits the inversion in the opposite direction from which it entered. The now defunct Drachen Fire featured a cutback.


Dive Loop Edit

KumbaDiveLoop

A Dive Loop.

A Dive Loop is an inversion that starts like a normal hill, then when it reaches its maximum steepness, does a corkscrew-like twist (which horizontally can range from straight to a curve over 135º) into a downwards half loop. When traveled in reverse it is usually called an "Immelman".


Inclined Loop Edit

ChangInclinedLoop

An Inclined Loop.

An Inclined Loop (or a Tilted Vertical Loop) is a Vertical Loop that has been "tilted" at an angle. It is not entered vertically, like a standard loop, or horizontally like a helix. Instead, it is usually entered at an angle between 45° and 80°.


Interlocking Corkscrews Edit

Kumba Corkscrews

Interlocking Corkscrews.

Interlocking Corkscrews are parallel (or near parallel) Corkscrews that cross over each other in opposite directions.


Interlocking Loops Edit

220px-BGE-Loch Ness Monster

Interlocking Loops.

Interlocking Loops are perpendicular (or near perpendicular) Vertical Loops that cross over each other, making a similar shape to that of a chain.


Norwegian Loop Edit

A Norwegian Loop is a Dive Loop and an Immelmann traveled in succession.


Sea Serpent Edit

A Sea Serpent (known as a Roll Over on Vekoma coasters) is an inversion pair that is very similar to a Cobra Roll, only the Corkscrew halves have a constant twist and curve in in the same direction (rather than mirroring the second half).



Butterfly Edit

A Butterfly is a variation of a Sea Serpent with very tight corkscrew halves (which appear to be "stretched Loop halves").



Sidewinder Edit

Sidewinder

A Sidwinder.

A Sidewinder is half of a Vertical Loop combined with half of a Corkscrew.


Vertical Loop Edit

VerticalLoopElement

A Vertical Loop.

The most generic roller coaster inversion is a vertical loop. The loop is a continuously upward-sloping section of track that eventually results in a complete 360° circle. At the top-most piece of the loop, riders are completely upside-down. The continuously upward slope often increases relatively as the altitude increases to average the G-Forces (this is often called a "Teardrop Loop").


Zero-G Roll Edit

HydraZeroG

A Zero-G Roll.

A Zero-G Roll (sometimes called a "Spiraling Camelback) is an inversion that is similar to a barrel roll but starts and ends vertically inclined like a standard hill. The inversion resembles a hill with a barrel roll on top.


Zero-G Stall Edit

Similar to a Zero-G Roll, a Zero-G Stall levels out upside down at its highest point, twisting at the ends before leveling off at or near ground level.


Top Gun Stall Edit

Similar to the Zero-G Stall, but the second half of is mirrored.
